Tapping Machine

We are Top Rated Tapping Machine, 5mm Tapping Machine Manufacturer in Jamnagar, Gujarat

We are a value-driven organization renowned in the industries as a celebrated manufacturer, supplier, and exporter of the tapping machine, a machine that is designed with the highest concentration to deliver the exemplary quality of tapping machine that is commendable for its précised tapping and no breaking of taps, thus reduce the cost of tapping ultimately.

The exemplary output of this tapping machine has made us recognized as a specialized tapping machine in the industries. This tapping machine is made employing top-quality cast iron material to impart sturdiness together with vibration-free and distortion-free operation.

This tapping machine gives outstanding efficiency and longer shelf life, in contrast to conventional belts, thanks to a strict quality check regime of our team which keeps an eye on quality beginning from the procuring of proven quality material to the delivery of the end product. The quality of our tapping machine is highly appreciated by a large group of clientele all around the world too.

Tapping Machine, Bench Tapping Machine, Manufacturers in Ahmedabad, Surat

5mm Tapping Machine Manufacturer

The accurate integration of the clutch assembly, gear drive, and spindle of the 5mm tapping machine is enabled to execute every operation with the highest accuracy. The spindle which is ingeniously integrated such that rotates in both anti-clock and clockwise directions, wherein the anti-clock rotation is set to rotate in the speed of the clockwise direction, is also the reason for eliminating the breaking of the tap.

Our in-house facilities and dexterous workforce are what have helped us to carry out the cutting-edge range of the tapping machine that is immensely applauded for its high efficiency, high output, precision output, smooth operation, and impeccable operation. Further, our customer-oriented approach is what facilitates us to edge over competitors within a short period. We provide this 5mm tapping machine is the widest spectrum as well as customized specifications, as detailed by clientele at competitive rates in the market.

TECHNICAL SPECIFICATIONS
Tapping Capacity 5 mm
No. Of Spindle Speed 530-810-1180-1730-2500
Spindle Nose Taper jacob 2 (1) taper
Spindle Center to Column 87 MM
Maximum Distance Between Chuck To Table 200 MM
Maximum Distance Between Working Surface To Table 157 x 129 MM
Column Diameter 41 MM
Base To Machine 378 x 223 MM
Overall Dimensions 630 x 360 x 495 MM
Motor Speed 1440 R.P.M.
Motor 3 Phase, induction, A.C. 0.37 KW. / 0.5 HP.
Weight of Machine (Approx.) 45 KG

Glance On The Best Features Of Tapping Machine

  • No breakage of tap and hence eliminates the need of tap skilled worker
  • The versatile arm tapping head deliver considerable accuracy with multiple taps and fittings
  • There is no need of the manual tapping, hence save time and labor too
  • Precisely grounded parts imparts long accurate working life
  • The adjustable screw is provided to adjust the tapping depth
  • The working table can be lifted, lowered and swiveled by hand with the use of the rack and gear

Here We Provide Exclusive Accessories & Equipment For Drill Machine

Standard Accessories: Pulley for Motor

Extra Accessories & Equipments: 0.50 HP 1440 RPM Electric Motor, Chuck, V-Belt, Switch.

Key Tag: Tapping Machine Manufacturer | 5mm Tapping Machine Manufacturer | Tapping Machine Exporter | Drill Machine Tools | Drill Machine Tools Manufacturer | Drill Machine Tools Supplier
